| Frequency Range | 5(3)–100 Hz |
| Constant Torque Range | 5(3)–50 Hz |
| Constant Power Range | 50–100 Hz |
| Insulation Class | F |
| Protection Class | IP44 / IP54 |
| Cooling Method | IC416 |
| Duty Type | S1 |
| Connection Mode | Y Connection for ≤ 55 kW; △ Connection for > 55 kW |
This series of electric motors sets the advantages of similar products at home and abroad. The speed range is wide, the vibration is small, and the noise is low.
The motor adopts a rat cage structure, running reliably and maintaining conveniently. A separate cooling fan is installed to ensure that the motor has a good cooling effect at different speeds.
| Type | Power(KW) | Rated current(A) | Rated torque(N.m) | Constant torque frequency range(Hz) | Constant power frequency range(Hz) |
| YVP 80M1-4 | 0.55 | 1.6 | 3.5 | 5-50 | 50-100 |
| YVP 80M2-4 | 0.75 | 2 | 4.7 | ||
| YVP 90S-4 | 1.1 | 2.9 | 7 | ||
| YVP 90L-4 | 1.5 | 3.7 | 9.5 | ||
| YVP 100L1-4 | 2.2 | 5.2 | 14 | ||
| YVP 100L2-4 | 3 | 6.8 | 19 | ||
| YVP 112M-4 | 4 | 9.2 | 25.4 | ||
| YVP 132S-4 | 5.5 | 11.8 | 35 | ||
| YVP 132M-6 | 7.5 | 15.6 | 47.7 | ||
| YVP 160M-4 | 11 | 22.3 | 70 | ||
| YVP 160L-4 | 15 | 30.1 | 95.5 | ||
| YVP 180M-4 | 18.5 | 36.5 | 117.1 | ||
| YVP 180L-4 | 22 | 43.4 | 140.9 | ||
| YVP 200L-4 | 30 | 57.6 | 190.9 | ||
| YVP 225S-4 | 37 | 69.9 | 235.5 | ||
| YVP 225M-4 | 45 | 84.7 | 286.4 | ||
| YVP 250M-4 | 55 | 103 | 350.1 | 3-50 | |
| YVP 280S-4 | 75 | 140 | 477.7 | ||
| YVP 280M-4 | 90 | 167 | 572.9 | ||
| YVP 315S-4 | 110 | 201 | 700.2 | ||
| YVP 315M-4 | 132 | 241 | 840.3 | ||
| YVP 315L1-4 | 160 | 292 | 1018.5 | ||
| YVP 315L2-4 | 200 | 365 | 1273.2 |
